New Generation of Rotary Laser Level
|
|
TRL122/TRL124
|
TRL131/TRL134
|
TRL154
|
TRL155
|
|
Laser Class
|
635nm RED, Class II/Class IIIA
|
|||
|
Working Range(Diameter)
|
300m(Customized)/600m(Default)/1000m(Customized)
|
|||
|
Self-leveling Range
|
±5°
|
|||
|
Self-leveling Accuracy(10m)
|
H: ±1mm;
V:±1mm(TRL124)
|
V:±1mm(TRL134)
|
H: ±1mm;
V:±1mm
|
H: ±1mm;
V:±1mm
|
|
Laser Plummet Accuracy
|
±1mm/1.5m(TRL124)
|
±1mm/1.5m
|
±1mm/1.5m
|
±1mm/1.5m
|
|
Manual Slope(Both Way)
|
±10%(TRL124)
|
±10%(TRL134)
|
±10%
|
±10%
|
|
Auto Slope/
Accuracy(Both Way)
|
±10%;0.1%(TRL124)
|
±10%;0.1%(TRL134)
|
±10%;0.1%
|
±10%;0.1%
|
|
Rotation Speed
|
5, 300, 600, 1000rpm
|
|||
|
Region Scan
|
0, 10°, 45°, 90°, 180°
|
|||
|
Remote Distance
|
30m(TRL124)
|
30m(TRL134)
|
30m
|
30m
|
|
Joint
|
5/8" x2
|
5/8" x2
|
5/8"
|
5/8"
|
|
Power Supply
|
7.4V(2600mAH)Lithium Battery Pack/2# Alkaline battery x4
|
7.4V(4400mAH)Lithium Battery Pack
|
||
|
External Power
|
12V DC
|
|||
|
Working time
|
18 h(Lithium battery)
|
30h
|
||
|
Working Temperature
|
-10°C to +50°C
|
|||
|
Water & Dust Proof
|
IP54
|
IP65
|
||
|
Dimension
|
220(L)x170(W)x210(H)
|
225(L)x175(W)x210(H)
|
190(L)x235(W)x235(H)
|
190(L)x235(W)x235(H)
|
|
Weight
|
2.4KGS
|
2.7KGS
|
3.5KGS
|
3.5KGS
|
